Akron Diamond heater No 17

Discussion in 'Other Pressure Apparatus' started by Bo Ryman, May 30, 2020.

  1. Bo Ryman

    Bo Ryman Founder Member Subscriber

    Offline
    Joined:
    Sep 13, 2010
    Messages:
    336
    I have had this beast standing in my barn for many years. Finally I have got the time to clean it up.
    I am afraid I won't be able to get it in working condition so for display only.
    The main problem is the manometer that is totally rotten. Only part of it is visible outside the shell, rest is inside an even more rusty.
    Anyway a hughe and heavy heater, probably 10kg:s or so.

    Bo

    IMG_20200530_160007.jpg IMG_20200530_160015.jpg IMG_20200530_160030.jpg IMG_20200530_160043.jpg IMG_20200530_160119.jpg IMG_20200530_160134.jpg IMG_20200530_160147.jpg

  2. Conny C

    Conny C Sweden Subscriber

    Offline
    Joined:
    Nov 29, 2010
    Messages:
    696
    Bo, you have done it again. A gem picked of from your barn, or should we say.... the museum of GPA,s! Great stuff :thumbup:!

    /Conny

  3. george

    george United States Subscriber

    Offline
    Joined:
    Nov 8, 2011
    Messages:
    2,031
    Location:
    USA
    Well done, Bo!
    :thumbup::D/

  4. JEFF JOHNSON

    JEFF JOHNSON United Kingdom Subscriber

    Offline
    Joined:
    Nov 28, 2010
    Messages:
    9,689
    Location:
    Shetland Islands UK..
    It's good to see an example!:thumbup:

  5. Lighthouse

    Lighthouse Sweden Subscriber

    Offline
    Joined:
    Jan 28, 2011
    Messages:
    168
    Location:
    Sweden
    Fascinating example of what must be a rare heater, Bo!
    Is that a second valve I spot in the third picture? What's its function?

  6. Bo Ryman

    Bo Ryman Founder Member Subscriber

    Offline
    Joined:
    Sep 13, 2010
    Messages:
    336
    There are two valves and one rod with a tiny knob. That one regulates a lid in front of the burner an has a spring return. Maybe some kind of choke mechanism?
    Bo
