Ca. 1910 Alcohol projector lamp

Discussion in 'Other Brands' started by Conny C, Nov 27, 2020.

  1. Conny C

    Conny C Sweden Subscriber

    Offline
    Joined:
    Nov 29, 2010
    Messages:
    727
    Hi all,

    This is an incandescent pressure alcohol projector lamp and is probably made around 1910.
    These type of lamps were the lighting source in a projection device,
    as a Magic Lantern (Skioptikon) or a Cinematograph.

    This lamp has a stamped numbering 19.1003 on the cast lamp stand.
    If this is a production number, it will probably be March 1910, as these type of
    alcohol burner lamps seem to be have been used for a short period around 1910.
    Later the carbon arc type of projection lighting took over from the early "Lime Light" and
    the alcohol incandescent lighting.
    This lamp is most likely German and also most likely made of Gustav Barthel.
    you can see a Barthel "Alpha" projection lamp with a nearly identical burner as on my lamp .... Alpha

    This is a tiny device and it was difficult to find a proper mantle for it. After a good clean-up and some adjustments, I was able to lit her up. This burners has an adjustable cap or tube to restrict the air intake. These pressure alcohol burners need more air intake restriction than you would anticipate, and is very sensible for the air/fuel mix ratio. Finally got a fine tuning and a good light outcome result; probably around 80 - 100 CP. A nice odd lamp for my collection.

    /Conny



    Projector-lamp-above-view.jpg Projector-lamp-burner-with-.jpg Projector-lamp-tank-with-ma.jpg Projector-lamp-valve-fibre-.jpg Projector-lamp-pre-heater-c.jpg Projector-lamp-height-adjut.jpg Projector-lamp-lamp-stand.jpg Projector-lamp-fuel-filler-.jpg Projector-lamp-jet-with-air.jpg Projector-lamp-stamped-digi.jpg Projector-lamp-with-beer-ca.jpg Projector-lamp-with-externa.jpg Projector-lamp-pre-heating.jpg Projector-lamp-Bunsen-flame.jpg Projector-lamp-lit.jpg Projector-lamp-lit2.jpg

    Here are some other alcohol projector lamps from around 1910 ……

    Ica-and-Barthel-projector-l.jpg alcohol-projector-lamps.jpg

  2. Matty

    Offline
    Joined:
    Mar 22, 2015
    Messages:
    2,504
    Location:
    Queensland, Australia
    Conny, Um..

    Conny, ah..

    I give up, I'm lost for words. Sensational as usual.

  3. Conny C

    Conny C Sweden Subscriber

    Offline
    Joined:
    Nov 29, 2010
    Messages:
    727
    Thanks Matt!

  4. JEFF JOHNSON

    JEFF JOHNSON United Kingdom Subscriber

    Offline
    Joined:
    Nov 28, 2010
    Messages:
    10,809
    Location:
    Shetland Islands UK..
    A splendid addition to your collection!:thumbup::thumbup:

  5. Fireexit1

    Fireexit1 United Kingdom Subscriber

    Offline
    Joined:
    Jun 13, 2020
    Messages:
    519
    Location:
    Brighton UK
    Astounding ! 99% of the planet would not even have recognised it for what it is. Conservation of history in action here all.
    Well done Conny - no-one here can fail to be impressed.

  6. ROBBO55

    ROBBO55 Subscriber

    Offline
    Joined:
    Oct 21, 2014
    Messages:
    2,181
    Location:
    Somersby, New South Wales, Australia
    Very nice, Conny. Congratulations :thumbup::thumbup::thumbup:

  7. Tony Press

    Tony Press Australia Subscriber

    Offline
    Joined:
    Aug 28, 2012
    Messages:
    6,810
    Location:
    Stinkpot Bay, Howden, Tasmania, Australia
    Excellent!

    Cheers

    Tony

  8. coleman54

    coleman54 United States Subscriber

    Offline
    Joined:
    Jul 21, 2020
    Messages:
    86
    Location:
    Oklahoma, USA
  9. Matty

    Offline
    Joined:
    Mar 22, 2015
    Messages:
    2,504
    Location:
    Queensland, Australia
    @coleman54

    Larry, G'day you old bas....

    Would you mind uploading that advert again but use full image rather than thumbnail? I'm only guessing you used thumbnail because the image is a bit small for my tired old eyes to read it.

  10. coleman54

    coleman54 United States Subscriber

    Offline
    Joined:
    Jul 21, 2020
    Messages:
    86
    Location:
    Oklahoma, USA
    Matt, that is full image it’s a small wide image. Here is the improved 1912 model.

  11. Matty

    Offline
    Joined:
    Mar 22, 2015
    Messages:
    2,504
    Location:
    Queensland, Australia
    Thanks Larry.


  12. Conny C

    Conny C Sweden Subscriber

    Offline
    Joined:
    Nov 29, 2010
    Messages:
    727
    @coleman54 @Matty

    Thanks Larry and Matt for those interesting alcohol projection lamp ads:thumbup:!
    I think the period around 1910, give and take a couple of years, is the right time period for these alcohol projector lamps!

    /Conny

  13. Jean J

    Jean J Subscriber

    Offline
    Joined:
    Jun 25, 2011
    Messages:
    1,890
    Location:
    N E Scotland
    Conny your wee lamp looks weirdly fascinating. Could you make a cup of coffee with it? (Just joking of course!).

  14. Brenneman

    Brenneman Netherlands Subscriber

    Online
    Joined:
    Nov 11, 2018
    Messages:
    50
    Location:
    The Netherlands
    I would love to see a video of this projector lamp fired up!

  15. Walkop Australia

    Offline
    Joined:
    Aug 28, 2020
    Messages:
    153
    Location:
    Bathurst, Australia
    Certainly history preserved. Amazing what devices were around in pre electric times.

  16. MYN

    Offline
    Joined:
    Feb 28, 2018
    Messages:
    1,887
    Location:
    Malaysia
    Very fascinating indeed. Makes me wonder what other lighting devices mankind would have develop if electrification is still as scarce today as it had been, a hundred years earlier.

  17. Dean D

    Dean D Subscriber

    Offline
    Joined:
    May 21, 2017
    Messages:
    54
    Location:
    Minnesota USA
    That's a wonderful piece of history.
    Thanks for sharing Conny

  18. Matty

    Offline
    Joined:
    Mar 22, 2015
    Messages:
    2,504
    Location:
    Queensland, Australia
    Something I honestly don't get is, why some inventions like electric plants that provided electricity for everything in the home aren't dusted off and put to good use in these days of bleeding heart global warming fanatics.

    Quirks had a plant that stored electricity in batteries. The batteries were charged by a a windmill and from all accounts worked very well. It must have worked well because they sold them for decades.

    I can only imagine technology has far surpassed what was available to Quirks including battery and light bulb (LED) technology.

    I have seen these magic lanterns in the 3 forms of burner type, non -pressure, pressure and hollow wire. The hollow wire mantle magic lamp is one of my favourite items I have found over the years.

  19. MYN

    Offline
    Joined:
    Feb 28, 2018
    Messages:
    1,887
    Location:
    Malaysia
    I love all these inventions. They do come in all sorts of shapes, sizes and geometries.
    Sometimes its the particular mechanism that's intriguing and interesting. Sometimes its sheer elegance and ingenuity in the ideas.

  20. Serge France

    Offline
    Joined:
    Aug 4, 2020
    Messages:
    6
    Location:
    France
    "Une merveille", Conny!
    As usual...

  21. BigStevie

    BigStevie United Kingdom Subscriber

    Offline
    Joined:
    Dec 5, 2018
    Messages:
    1,605
    Location:
    Scottish Highlands
    Another fascinating and beautiful lamp, always a pleasure to see your posts. Thank you for sharing.

  22. Walkop Australia

    Offline
    Joined:
    Aug 28, 2020
    Messages:
    153
    Location:
    Bathurst, Australia
    @Matty Have seen a the remants of those 32 volt wind/battery lighting plants on old farms. Apparently they worked quite well.

    Nowadays it is standalone solar/battery plants for where the cost of mains electricity is prohibitive.
