Canadian Coleman lantern pumps

Discussion in 'Coleman' started by Flygt, Nov 12, 2012.

  1. Flygt

    Offline
    Joined:
    Nov 8, 2012
    Messages:
    175

    From left to right #1-#17 including the large painted pump are an early style 1910's through to about late 1920's Coleman lamp and lantern pumps, first 3 are 7" pumps for irons, next 5 are 11" pumps, next 8 are 10" pumps, the large pump in the center is painted brass, but I've also seen these as nickel plated and unpainted brass.

    #18 through # 25 are later Coleman 1930's through to 1950's pumps as they have the brass pump shaft collar, shorter ones are 7" iron pumps, longer are 10" lamp pumps.

    #26 is an AGM pump

    #27 and #28 are unidentified and possibly medical pumps but work great for pressuring up lamps.

    #29 is unidentified and looks similar to Coleman but has a different type of shaft collar and the wooden handle is smaller.

    Last edited by a moderator: Mar 31, 2017
  2. Ryan Center United States

    Offline
    Joined:
    Jun 13, 2020
    Messages:
    13
    Location:
    Arkansas
    Thanks so much for the info!!
