Very small machine screws

Discussion in 'Fettling Forum' started by ColinG, Jun 4, 2021.

  1. ColinG

    ColinG United Kingdom Subscriber

    Offline
    Joined:
    Oct 2, 2017
    Messages:
    3,548
    I found this tiny pot of machine screws in a junk shop. They are absolutely tiny but I wasn't sure what thread they are but I had an inkling they might be BA so I checked them with my BA tap and die set and they're 10BA!!!



    I was looking to maybe use one to replace the screw that keeps the Bialaddin control know on the shaft but these are way too small! Nevermind, I'm sure I'll find a use for them one day!

    BTW, the OD is 1.7mm!

  2. JonD

    JonD Subscriber

    Offline
    Joined:
    Apr 15, 2014
    Messages:
    849
    Location:
    Hertfordshire, England
    They're huge @ColinG.
    A recent project here used 13BA.
    Drill 0.8mm then Tap M1


    Last edited: Jun 6, 2021
  3. ColinG

    ColinG United Kingdom Subscriber

    Offline
    Joined:
    Oct 2, 2017
    Messages:
    3,548
    13BA! That's incredible!

  4. JonD

    JonD Subscriber

    Offline
    Joined:
    Apr 15, 2014
    Messages:
    849
    Location:
    Hertfordshire, England
    They came from here.

    BA Fasteners, Imperial Fasteners, Micro Metric Stainless, Small Screws, UNC Square Nuts, Ba Screws, Ba Bolts,

    That is a switch rotor from a piece of radio test equipment. The fingers are mounted by plastic pips which go brittle and the contacts fall off and get lost.
    I machined that pair of contacts and refitted them using the screws. Hope not to have to go in there again since assembling the unit is very awkward.

    Sorry about off topic - but hopefully someone might find the screw link useful.

  5. steerpike451

    steerpike451 United Kingdom Subscriber

    Offline
    Joined:
    Jun 29, 2016
    Messages:
    103
    Location:
    Norfolk, UK.
    Believe it or not, the original BA specification goes down to 25 BA (od 0.25mm), although I don't think anyone went much below 16 BA. FYI the retaining screw in the Bialaddin knob is 6 BA- positively chunky!

  6. MYN

    Offline
    Joined:
    Feb 28, 2018
    Messages:
    2,081
    Location:
    Malaysia
    Possibly, if you're going to fix something like a mechanical wrist watch.
